Geothermal Energy: Technology Overview and Use Cases

Master the Moment and Reach Your Peak with Defoes

“Defoes opens up the geothermal toolbox — from conventional hydrothermal plants to EGS, district heat and shallow loops — to show how a family of heat‑based technologies can evolve from niche projects into a diversified, infrastructure‑grade platform for 24/7 low‑carbon power and heat.”

Geothermal sits in an unusual position in the energy transition: it is a renewable resource that can behave like conventional baseload, yet it remains a tiny share of installed capacity and investor focus. The underlying physics are straightforward: the Earth’s internal heat creates temperature gradients that can be tapped for power and heat using wells, pipes and heat‑exchange systems. The investment question is whether current and emerging technologies can turn that steady but location‑tethered resource into scalable, financeable assets across more markets. From a Defoes perspective, the bullish stance is that the technology toolkit is now broad enough — and the system need for 24/7 low‑carbon energy acute enough — that geothermal is likely to move from niche to material in specific geographies and applications.

Core technology families

At its simplest, geothermal technology falls into four main families.

1. Conventional hydrothermal power
   These plants exploit naturally occurring combinations of heat, water and permeability. Wells tap into hot reservoirs, bringing high‑temperature fluid to the surface to drive a turbine directly (flash steam) or indirectly via a working fluid with a low boiling point (binary cycle). This is the workhorse technology in places like Iceland, Indonesia, the Philippines and parts of the US and East Africa. It is proven, can run at high capacity factors, and is now an established infrastructure asset class in favourable geology.

2. Enhanced geothermal systems (EGS)
   EGS targets hot rock where natural permeability and fluid are insufficient. Developers drill deep wells, stimulate fractures to create a heat‑exchange network in the rock, and circulate water through that engineered reservoir to bring heat to the surface. Technically, this extends geothermal far beyond volcanic belts into “hot but tight” crust under large parts of North America, Europe and elsewhere. It is earlier‑stage than hydrothermal, with higher resource and execution risk, but it is the key to turning geothermal from geographically constrained to broadly available.

3. Direct‑use and district‑heating systems
   Here the objective is heat, not power. Wells draw warm water or brine for space heating, greenhouses, aquaculture, industrial processes and district networks. Temperatures can be lower than for electricity production, which opens much larger areas to viable projects and often reduces technical complexity. For many cities and industries, decarbonising heat is more challenging than power; geothermal can deliver low‑carbon baseload heat without the volatility of gas prices.

4. Ground‑source (shallow) heat pumps
   These systems use the shallow subsurface as a thermal reservoir. Closed‑loop pipes circulate a fluid through boreholes or horizontal loops, and heat pumps move energy between the ground and buildings. Individually these look like building‑scale HVAC upgrades, but at neighbourhood scale they become a distributed geothermal‑based heat infrastructure. They rely on electricity for the heat pumps, but they drastically reduce delivered heat emissions when paired with a decarbonising grid.

Key advantages and constraints

Technically, geothermal’s defining advantage is dispatchable, high‑availability output. Wells and reservoirs, once proven, can provide very high capacity factors, often comparable to or exceeding nuclear and far above wind and solar. The “fuel” is local, essentially inexhaustible on human timescales at appropriate production rates, and hedges exposure to global fuel markets. Land and visual footprints are relatively modest compared with other renewables, especially for power plants and direct‑use sites.

The constraints are equally structural. Resource risk is front‑loaded: until you drill and test, you do not know the reservoir’s temperature, flow rates, chemistry or sustainability, which creates exploration‑driven uncertainty. Capital intensity per site is high, particularly for deep wells and EGS, and cost overruns in drilling can erode economics quickly. Induced seismicity from stimulation and subsidence from long‑term extraction must be managed carefully to maintain public acceptance. Regulatory frameworks in many countries were written for hydrocarbons or mining and have not fully adapted to geothermal’s mixed status as both a subsurface and a clean‑energy activity.

Use‑case landscape

For investors, the technology stack translates into a clear, differentiated set of use cases.

• Baseload renewable power in high‑resource regions
  In geologically favourable countries, utility‑scale geothermal plants can supply a material share of grid electricity. These projects often resemble other independent power producer (IPP) assets with long‑term offtake contracts, making them natural candidates for infrastructure and yield‑focused capital. They are especially attractive where geothermal can displace oil‑ or diesel‑fired generation.

• Firm capacity complementing high renewables
  In systems with large wind and solar fleets, geothermal can operate as firm low‑carbon capacity that flattens net demand and reduces the need for storage and peaking plants. That role strengthens the case for favourable market design — capacity payments, ancillary‑service revenues, or long‑duration contracts — all of which improve bankability.

• Industrial and urban heat decarbonisation
  Direct‑use and district‑heating projects can serve breweries, food processing, greenhouses, data centres and municipal heating grids. In many of these cases, geothermal competes not with other renewables but with gas boilers and combined heat and power plants. The revenue is essentially a long‑term heat‑supply contract, often linked to regulated tariffs or municipal plans.

• Shallow geothermal and thermal networks
  At building and district scale, ground‑source heat‑pump systems and ambient‑temperature loop networks provide a path to electrify heating without overloading electric systems at peak times. The investment profile resembles distributed infrastructure: capital‑heavy upfront, long asset lives, and relatively stable service revenues where regulations support cost recovery.

• EGS‑driven expansion into new markets
  If EGS and closed‑loop concepts reach reliable commercial scale, they open the door to geothermal power and heat in regions currently considered uneconomic. That creates potential for portfolio strategies: early stakes in EGS platforms, combined with traditional hydrothermal and direct‑use assets, to diversify geology and technology risk.

A bullish but selective view

The bear case is clear: exploration risk, drilling complexity, site specificity and evolving regulation make geothermal harder to industrialise than modular solar or wind. Not every country will have attractive enough resources, and not every promising reservoir will perform as models predict.

Yet the energy‑system need is also clear. As grids decarbonise and heating transitions away from fossil fuels, demand for firm, local, low‑carbon heat and power will rise rather than fall. Geothermal’s technology suite — from conventional hydrothermal plants to EGS reservoirs, district‑heat systems and shallow loops — is well suited to that demand, but capital and policy have only recently begun to adjust. From a Defoes standpoint, the bullish stance is that geothermal is likely to become a core option in specific markets where geology, policy and heat or power demand align — and that investors who treat it as a serious infrastructure technology rather than a curiosity will be better placed as the resource moves from underexplored to systematically developed.
